Features:
1. Innovate AGM technology, special lid design, ultra high efficiency of oxygen compound, which make battery maintenance free completely, eco-friendly, and safe to slant in any angle.
2. Lead carbon technology make battery with good starting ability in low temperature, and fast charging acceptance.
3. Radial design grids, and tight assembly technology, which make battery with good vibration resistance, reduce the engine abrasion rate.
4. Excellent anti-corrosion alloy material and high pure material, battery with longer cycle life. low self-discharge, long storage time.
5. Wider working temperature, -40℃~70℃. Cycle life is 3 times as ordinary start stop battery.
Application:
Hybrid cars
Start - stop
System equipped vehicles and also ordinary cars
Specification:
Model | Norminal Voltage（V） | Capacity (Ah/20Hr) | Reserve Capacity (min) | CCA(A) | Dimension (mm) | Weight (kg±3%) | Terminal | Terminal Position | ||
L | W | H | ||||||||
VRL2 60-H5 | 12 | 60 | 100 | 660 | 242 | 175 | 190 | 18.7 | AP | B |
VRL3 70-H6 | 12 | 70 | 120 | 720 | 278 | 175 | 190 | 21.5 | AP | B |
VRL4 80-H7 | 12 | 80 | 140 | 800 | 315 | 175 | 190 | 24.5 | AP | B |
VRL5 92-H8 | 12 | 92 | 160 | 850 | 353 | 175 | 190 | 27.5 | AP | B |
VRL6 105-H9 | 12 | 105 | 190 | 950 | 394 | 175 | 190 | 30.5 | AP | B |
All data and specifications are subjected to change without notice, please contact MCA to confirm information. | ||||||||||
