Features:
1. High quality fumed silica gel electrolyte：no flow, no leakage, all parts of the plate in uniform reaction.
2. Tight assembly technology: high efficiency discharge performance.
3. Gel electrolyte, battery with good heat dissipation ability, battery can work at lower and higher temperature.
4. High purity raw material: low self discharge rate.
5. Oxygen recombination technology: safe and eco-friendly.
Applications:
Solar energy system
Uninterrupted power suppliers
Lighting equipment, fire alarms and security systems
Communication and telecom system
Specification:
Model | Norminal Voltage（V） | Capacity (Ah) | Dimension (mm) | Weight (kg±3%) | Terminal | Terminal Position | Screw | |||
L | W | H | Total H | |||||||
12 | 24/10HR | 165 | 126 | 174 | 174 | 7.8 | T2 | B | M6×16 | |
12 | 26/10HR | 166 | 175 | 126 | 126 | 8.4 | T2 | B | M6×16 | |
12 | 33/10HR | 196 | 130 | 155 | 167 | 10.1 | T3 | A | M6×16 | |
12 | 38/10HR | 198 | 166 | 174 | 174 | 12.4 | T2 | B | M6×16 | |
12 | 42/10HR | 198 | 166 | 174 | 174 | 13 | T2 | B | M6×16 | |
12 | 50/10HR | 229 | 138 | 208 | 212 | 15.9 | T3 | A | M6×16 | |
FCG12-55AT | 12 | 55/10HR | 229 | 138 | 208 | 212 | 16.4 | T3 | A | M6×16 |
FCG12-58AT | 12 | 58/10HR | 229 | 138 | 208 | 212 | 17.4 | T3 | A | M6×16 |
FCG12-65AT | 12 | 65/10HR | 350 | 167 | 178 | 178 | 20.3 | T3 | B | M6×16 |
FCG12-65BT | 12 | 65/10HR | 350 | 167 | 178 | 178 | 20.6 | T3 | A | M6×16 |
FCG12-70AT | 12 | 70/10HR | 350 | 167 | 178 | 178 | 21.4 | T3 | B | M6×16 |
FCG12-70BT | 12 | 70/10HR | 260 | 169 | 211 | 215 | 21.8 | T3 | A | M6×16 |
FCG12-75AT | 12 | 75/10HR | 260 | 169 | 211 | 215 | 22.2 | T3 | A | M6×16 |
FCG12-80AT | 12 | 80/10HR | 331 | 174 | 214 | 219 | 25 | T4 | B | M8×18 |
FCG12-80BT | 12 | 80/10HR | 260 | 169 | 211 | 215 | 23.5 | T3 | A | M6×16 |
FCG12-80BP | 12 | 80/10HR | 260 | 169 | 211 | 231 | 23.5 | L4 | A | M8×18 |
FCG12-90AT | 12 | 90/10HR | 307 | 169 | 211 | 215 | 26.7 | T3 | A | M6×16 |
FCG12-90BT | 12 | 90/10HR | 331 | 174 | 214 | 219 | 28 | T4 | B | M8×18 |
FCG12-95AT | 12 | 95/10HR | 407 | 174 | 208 | 233 | 29.7 | T5 | A | M8×18 |
FCG12-100AT | 12 | 100/10HR | 331 | 174 | 214 | 219 | 29.2 | T4 | B | M8×18 |
FCG12-100BT | 12 | 100/10HR | 328 | 172 | 218 | 222 | 29.2 | T4 | A | M8×18 |
FCG12-100LT | 12 | 100/10HR | 331 | 174 | 214 | 219 | 30.7 | T4 | B | M8×18 |
FCG12-120BT | 12 | 120/10HR | 407 | 174 | 208 | 233 | 34.2 | T5 | A | M8×18 |
FCG12-150AT | 12 | 150/10HR | 484 | 171 | 241 | 241 | 43.7 | T4 | A | M8×18 |
FCG12-160AT | 12 | 160/10HR | 532 | 206 | 215 | 219 | 48.5 | T4 | C | M8×18 |
FCG12-180BT | 12 | 180/10HR | 532 | 206 | 215 | 219 | 52.4 | T4 | C | M8×18 |
FCG12-200AT | 12 | 200/10HR | 522 | 240 | 219 | 223 | 58.5 | T5 | C | M8×18 |
FCG12-220BT | 12 | 220/10HR | 520 | 268 | 203 | 207 | 68.3 | T5 | C | M8×18 |
FCG12-250AT | 12 | 250/10HR | 520 | 268 | 220 | 224 | 70.3 | T5 | C | M8×18 |
FCG6-130AT | 6 | 130/10HR | 260 | 180 | 246 | 252 | 20.6 | T5 | F | M8×18 |
FCG6-180AT | 6 | 180/10HR | 260 | 180 | 246 | 252 | 27.6 | T5 | F | M8×18 |
FCG6-180BT | 6 | 180/10HR | 306 | 168 | 220 | 226 | 26.1 | T5 | F | M8×18 |
FCG6-200AT | 6 | 200/10HR | 260 | 180 | 246 | 252 | 29.6 | T5 | F | M8×18 |
FCG6-200BT | 6 | 200/10HR | 323 | 178 | 226 | 230 | 29.6 | T5 | E | M8×18 |
All data and specifications are subjected to change without notice, please contact MCA to confirm information. | ||||||||||
